Basic Info.
Model NO.
UL10126
Conductor Material
Copper
Insulation Material
PVC
Material Shape
Round Wire
Range of Application
Flame Retardant
Certification
ISO9001, RoHS, Reach
Brand
B&T
Rated Temperature
80 ºC
Rated Voltage
300V
According to
UL Subject758, UL1581, C22.2
Test
Passes UL VW-1 FT1 Vertical Flame Test
Performance
for General Purpose Internal Wiring of Appliance
Conductor
Stranded, Tinned or Bare Copper Conductor
Capacity
300,000km Annual
Color
Could Be Customized Color
Delivery Time
7-15days
Package
Coil or Spool Packing
Transport Package
610feet in Roll
Specification
UL1061
Trademark
B&T
Origin
Xiamen, Fujian
HS Code
8544492100
Production Capacity
300, 000km
Packaging & Delivery
Package Size
20.00cm * 20.00cm * 15.00cm
Package Gross Weight
0.200kg
Product Description
UL10126 600V 150C ETFE Insulation tinned bare copper conductor electrical wire
Our products Application Areas:
Our products can meet UL, VDE, CCC, PSE certificate requirement and the products are accord with ROHS and REACH Halogen free standard.
Our factory could meet ISO9001:2008 management systems standard. There are 6 production lines in high quality, precise, automation which supporting daily capacity 300,000km cables at least.
Q1: Can I get a free sample?
A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.
Q2: How could I pay?
A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q3: What is your packing way? Can I have the customized package?
A3: We have the standard export package. For more details about the customized package, please contact us.
Q4: What is the delivery lead time?
A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q5: Are you a factory or a trading company?
A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Q6: Where is your main market?
A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.
Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional service
Why choose us
1. Production
Qualified production, competitive price, professional service.
2. Technology
Professional R& D team
3. Equipment
With completive testing equipment.
4. Quality
UL/ CE/ FCC/ RoHS/ Reach certificate
PRODUCT DESCRIPTION:
Rated temperature:150ºC
Rated voltage:600V
According to:UL Subject758,UL1581,C22.2
Tin/bare copper conductor
ETFE Insulation
Passes UL VW-1 FT1 vertical flame test
Uniform insulation thickness of wire to ensure easy stripping and cutting
For general purpose internal wiring of appliance
| AWG | NO.of Cond | Conductor resistance 20ºC | Conductor Dia | Insulation Thickness | Overall Diameter | ||
| (mm) | (Ω/KM) | (mm) | (mm) | (mm) | |||
| Nom. | Min. | Nom. | Tol. | ||||
| 10 | 37/0.42 | 3.54 | 2.94 | 0.40 | 0.33 | 3.75 | ±0.15 |
| 12 | 37/0.374 | 5.64 | 2.62 | 0.40 | 0.33 | 3.42 | ±0.15 |
| 14 | 19/0.361 | 8.96 | 1.85 | 0.25 | 0.23 | 2.35 | ±0.10 |
| 16 | 19/0.287 | 14.60 | 1.50 | 0.25 | 0.23 | 2.00 | ±0.10 |
| 18 | 19/0.235 | 23.20 | 1.18 | 0.25 | 0.23 | 1.70 | ±0.10 |
| 20 | 19/0.19 | 36.70 | 0.95 | 0.25 | 0.23 | 1.45 | ±0.10 |
| 22 | 19/0.15 | 59.40 | 0.76 | 0.25 | 0.23 | 1.26 | ±0.10 |
| 24 | 7/0.20 | 94.20 | 0.60 | 0.25 | 0.23 | 1.10 | ±0.10 |
| 26 | 7/0.16 | 150.00 | 0.48 | 0.25 | 0.23 | 1.00 | ±0.10 |
| 28 | 7/0.127 | 239.00 | 0.38 | 0.25 | 0.23 | 0.90 | ±0.10 |
| 30 | 1/0.254 | 361.00 | 0.254 | 0.25 | 0.23 | 0.75 | ±0.10 |
