Basic Info.
Colour
Red/Green/Blue/Black/White/as Request
OEM/ODM
Yes
Flame Test
Yes
Cross Section
14AWG 12AWG 10AWG 8AWG 6AWG
Transport Package
Soft Packing
Specification
14--6AWG
Trademark
feiya
Origin
Tianjin, China
HS Code
8544492100
Product Description
* Product standard:
The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005,GB/T5023-2008,JB/T8734-2012
* Main of cables features
1,Uo/U is 450/750V,300/500,
2,Long-term allowable temperature of the cable:The allowable temperature of 105 Cable should not exceed 105ºC, the allowable temperature of other models should not exceed 70ºC.
* Application:
Applicable to the cables and wires of rated yolatage 450/750V and less than 450/750V AC for power plant, household electrical applance,insurment and telecommunication equipment.cable electrric for Control signal transmission
The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005,GB/T5023-2008,JB/T8734-2012
* Main of cables features
1,Uo/U is 450/750V,300/500,
2,Long-term allowable temperature of the cable:The allowable temperature of 105 Cable should not exceed 105ºC, the allowable temperature of other models should not exceed 70ºC.
* Application:
Applicable to the cables and wires of rated yolatage 450/750V and less than 450/750V AC for power plant, household electrical applance,insurment and telecommunication equipment.cable electrric for Control signal transmission
| SIZE OF CONDUCTOR | No.&Nominal Diameter of Wire | Wall Thickness | Approximate Overall Diameter | Minimum Insulation Resistance | *Ampacity | Cable Nominal Weight | |||
| MM | Approximate AWG | MM | MM | MM | M-Ohm-Km | 90ºC wet | 90 ºC dry | KG/KM | |
| Solid | | PVC | Nylon | | | | | | |
| 1.6mm | 14 | 1x1.60mm | 0.4 | 0.10 | 2.60 | 130 | 35 | 35 | 22.62 |
| 2.0 mm | 12 | 1x2.00mm | 0.4 | 0.10 | 3.00 | 110 | 40 | 40 | 33.57 |
| 2.6 mm | 10 | 1x2.60mm | 0.5 | 0.10 | 3.80 | 120 | 55 | 55 | 55.78 |
| 3.2 mm | 8 | 1x3.20mm | 0.8 | 0.13 | 5.06 | 120 | 75 | 75 | 88.33 |
| Stranded | | | | | | | | | |
| 2.0mm2 | 14/7 | 7X0.60mm | 0.4 | 0.10 | 2.80 | 130 | 30 | 35 | 23.51 |
| 3.5mm2 | 12/7 | 7x0.80mm | 0.4 | 0.10 | 3.40 | 110 | 35 | 40 | 39.12 |
| 5.5mm2 | 10/7 | 7x1.00mm | 0.5 | 0.10 | 4.20 | 120 | 50 | 55 | 60.56 |
| 8.0mm2 | 8/7 | 7x1.20mm | 0.8 | 0.13 | 5.46 | 120 | 65 | 75 | 91.95 |
| 14mm2 | 6/7 | 7x1.60mm | 0.8 | 0.13 | 6.66 | 100 | 95 | 105 | 151.77 |
| 22mm2 | 4/7 | 7x2.00mm | 1.0 | 0.15 | 8.30 | 100 | 130 | 140 | 236.65 |
| 30mm2 | 2/7 | 7x2.30mm | 1.0 | 0.15 | 9.20 | 100 | 160 | 170 | 306.50 |
| 38mm2 | 1-19 | 19x1.60mm | 1.3 | 0.18 | 10.96 | 100 | 185 | 195 | 409.82 |
| 50mm2 | 1/0-19 | 19x1.80mm | 1.3 | 0.18 | 11.96 | 100 | 220 | 235 | 509.05 |
| 60mm2 | 2/0-19 | 19x2.00mm | 1.3 | 0.18 | 12.96 | 80 | 250 | 260 | 618.96 |
| 80mm2 | 3/0-19 | 19x2.30mm | 1.3 | 0.18 | 14.96 | 80 | 300 | 320 | 804.44 |
| 100mm2 | 4/0-19 | 19x2.60mm | 1.3 | 0.18 | 15.96 | 80 | 355 | 370 | 1013.94 |
| 125mm2 | 250MCM | 37x2.10mm | 1.6 | 0.18 | 18.26 | 80 | 400 | 420 | 1296.37 |
| 150mm2 | 300MCM | 37x2.30mm | 1.6 | 0.20 | 19.7 | 80 | 440 | 475 | 1542.02 |
| | 350MCM | 37x2.47mm | 1.6 | 0.20 | 20.90 | 60 | 505 | 523 | 1783.07 |
| 200mm2 | 400MCM | 37x2.60mm | 1.6 | 0.20 | 21.80 | 60 | 540 | 570 | 1946.72 |
| | 500MCM | 37x2.95mm | 1.6 | 0.20 | 24.25 | 60 | 620 | 655 | 2486.02 |
| 250mm2 | 500MCM | 61x2.30mm | 1.6 | 0.20 | 24.30 | 60 | 620 | 655 | 2437.34 |
| | 600MCM | 61x2.52mm | 1.8 | 0.23 | 26.76 | 60 | 690 | 710 | 2995.93 |
| 325mm2 | 650MCM | 61x2.60mm | 1.8 | 0.23 | 27.46 | 60 | 720 | 770 | 3191.58 |
| | 750MCM | 61x2.82mm | 1.8 | 0.23 | 29.36 | 60 | 785 | 820 | 3719.63 |
| 400mm2 | 800MCM | 61x2.90mm | 1.8 | 0.23 | 30.16 | 60 | 810 | 875 | 3927.55 |
| 500mm2 | 1000MCM | 61x3.20mm | 1.8 | 0.23 | 32.86 | 60 | 930 | 995 | 4750.91 |
