Basic Info.
Product Description
ONE-STOP SOLUTIONS FOR WIRES&CABLES - HENAN UME CABLE CO., LTD
Over 30 years of Wires and Cables manufacture experience and Export to over 50 countries.
1. Applications
BS6004 Flat Twin & Earth Wire 6242Y
| Nominal Cross Section | Phase Conductor | Insulation | Earth Conductor | Outer Sheath | Approx. Weight | |||||||
| No. of Wires/ Dia.of Wire | Conductor Dia. | Nominal Thickness | Insulation Dia. | No. of Wires | Dia. of Wire | Conductor Dia. | Nominal Thickness | Overall Dia. | ||||
| mm2 | No./mm | mm | mm | mm | No. | mm | mm | mm | mm | kg/km | ||
| 2x1.0+1.0 | 1/1.13 | 1.13 | 0.6 | 2.33 | 1 | 1.13 | 1.13 | 0.9 | 7.59x4.13 | 63.9 | ||
| 2x1.5+1.0 | 1/1.38 | 1.38 | 0.7 | 2.78 | 1 | 1.13 | 1.13 | 0.9 | 8.49x4.58 | 80.3 | ||
| 2x2.5+1.5 | 1/1.78 | 1.78 | 0.8 | 3.38 | 1 | 1.38 | 1.38 | 1.0 | 10.14x5.38 | 118.5 | ||
| 2x4+1.5 | 7/0.85 | 2.55 | 0.8 | 4.15 | 1 | 1.38 | 1.38 | 1.0 | 11.68x6.15 | 157.8 | ||
| 2x6+2.5 | 7/1.04 | 3.12 | 0.8 | 4.72 | 1 | 1.78 | 1.78 | 1.1 | 13.42x6.92 | 218.6 | ||
| 2x10+4 | 7/1.35 | 4.05 | 1.0 | 6.05 | 7 | 0.85 | 2.55 | 1.2 | 17.05x8.45 | 346.7 | ||
| 2x16+6 | 7/1.70 | 5.10 | 1.0 | 7.10 | 7 | 1.04 | 3.12 | 1.3 | 19.92x9.70 | 501.5 | ||
HENAN UME CABLE CO., LTD has a strict quality control policy in every step from the order to After-sales service!
Production:
- Raw material inspection and test
- Production process test
- Unqualified product control
- Regular test and examination
- Finished product inspection
UME Cable was founded in 1994, located in Zhengzhou Gongyi Huiguo Town, and occupies a total area of more than 200,000 square meters, with a building area of 20,000 square meters. The real capital assets are more than USD 6 million, with a total of 230 staff members, 35 of which are professional and technical experts. The land of our factory and employees numbers might not be the top scale of industry, but our highly automatic facilities and elite employees are the best in the industry will guarantee you a high yield rate achieved by strict cost and quality control, this is why we could quote better quality with the most competitive price within the market.
Q1: Are you a manufacturer?
Yes, we are the manufacturer.
Q2: What are your main products?
Our products range as follows:
1. Electrical wire/PVC Building Wires.
2. PVC/XLPE insulated Power Cables up to 110kv.
3. Overhead Aerial Bundle Cable/ABC Cables.
4. Bare Conductors, like AAC, AAAC, ACSR, ACAR, ASCR/AW, and so on.
5. Steel wire/strand-like EHS, GSW and ACS(Aluminum Clad Steel), CCS(Copper Clad Steel).
6. Rubber Cables, Mining Cables, Welding Cable, and Control Cables.
7. Concentric Cables with Copper/Aluminum/Aluminum Alloy 8000s' Conductor.
Q3: Do you provide samples? Is it free or extra?
Yes, we could offer the samples for free
Q4: Is the quality of your products guaranteed?
We have passed ISO9001, ISO14001, ISO45001, and all our products have CE certificates.
Q5: Which markets do you involve mainly in?
Our products have been exported mainly to Africa, the Middle East, Southeast Asia, South America, Central America, North America, Europe, Australia, etc.
Q6: What is your payment term?
T/T or L/C
Q7: What about the delivery time?
Generally, it is 3-7days if the goods are in stock. Or it is 7-30days if the goods are not in stock, it is according to quantity.
