Basic Info.
Model NO.
NMD90
Range of Application
Electrical, Building
Certification
ISO9001, CE, CCC, RoHS, CSA
Brand
Ht Cables
Material
Copper
Insulation
PVC
Jacket
PVC
Standard
UL
Certificate
UL719
Color
Customized
Size
14/2 12/2 10/2
Transport Package
Roll
Specification
14/2 14/3 12/2
Origin
Hebei, China
HS Code
8544492100
Production Capacity
500000
Product Description
TOP TEN CABLE MANUFACTURER/EXPORTER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 400MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO14001,ISO45001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY
Applications:
NMD90 cables may be used for both exposed work in dry locations or concealed work in dry or
damp locations.The maximum allowable conductor temperature is 90°C. The minimum
recommended installation temperature is -25°C or -40°C for two-conductor cables and -25°C for
three-conductor cables (with suitable handling procedures). Material should be properly stored
above 0°C for 24 hours prior to installation. The maximum voltage rating for all intended
applications is 300 volts. Consult the Canadian Electrical Code1 for further information related to
applications.
Standards:
CSA C22.2 No. 48
