Basic Info.
Product Description
We Provide You The Largest Single Residential Battery On The Market With Easy Installation!
• Safe Lithium Iron Phosphate Technology (LiFeP04)
• High Durability and Long-Lasting
• Closed Loop Communication with Inverters
• Scalable from 5 kWh - 80 kWh
• Intelligent Digital Processor Based Battery Management System(BMS)
• Advanced cell level monitoring and balancing
• Matched more than 20 brand inverters, include the SMA, VICTRON and so on
• LCD screen performance display
| Electrical Specifications | |
| NomiNal Voltage | 51.2V |
| Nominal Capacity | 300Ah |
| Rated Capacity @ 0.5C(50A) | 15.36kWh |
| Resistance | <40Ω |
| Communication Protocol | RS485, RS232,CAN |
| Efficiency (@0.5C) | 98% |
| Cell Self-Discharge | <2% |
| Max Allowed Modules in Parallel | 8 |
| Depth of Discharge | Up to 100% |
| Warranty | 10 Years |
| Cycle Life | 6000(@60%) |
| Charge Specifications | |
| Recommended Charge Current | 0.3C |
| Max Charge Current | 0.5C |
| Recommended Charge Voltage | 54.4V |
| BMS Charge Voltage Disconnect | >56V |
| Discharge Specifications | |
| Recommended Continuous Discharge Rate | 0.5C |
| Peak Discharge Rate | 100Ah |
| Max Surge Power Rate | 110A |
| Recommended Low Voltage Disconnect | 48V |
| Battery Low Voltage Protection | <46V |
| Battery Recovery Voltage | 47V |
| Mechanical Specifications | |
| Dimensions:(L*W*H) | Customized |
| Weight | 180Kg |
| Terminal Type | Customized |
| Ring Terminal Size | Customized |
| Terminal Torque | Customized |
| Case Material | Q235A,Thickness 1.5~2mm |
| Enclosure Protection | Customized |
| Cell Type Chemistry | Professional Energy Storage Battery Prismatic LiFePO4 cELL |
| Temperature Specifications | |
| Discharge Temperature | -4°F~140°F(-20ºC~60ºC) |
| Charge Temperature | 32°F~120°F(0ºC~49ºC) |
| Storage Temperature | 6 months:14°F~77°F(-10ºC~25ºC) 3 months:-4°F~113°F(-20ºC~45ºC) |
Why a Familiy need the Energy Storage Battery?
1. Self-powered home
Use solar and Hyliess products to reduce reliance on the grid and run your home by solar day and night.
2 .Backup Power
Protect your home from a power outage with seamless and reliable backup power.
3.Energy saving
Reduce your electricity bill, if your utility offers a time-of-use rate plan.
4.Home energy control
Manage and control your home energy use our mobile App
5. What's your delivery time?
Sample Order within 7-10 days, and the bulk production within 15-20 days.
6. What is the payment Term?
T/T, L/C, WesternUnion
7. Are you a factory or a trading company?
We are a factory with more than ten years of experience in the production of solar energy series products. Welcome to Visit.
8. Can you support OEM and field installation?
Normally we only make our own brand, if you have a huge quantity we can discuss it.
