Basic Info.
Brand
Feiya
Colour
Red/Green/Blue/Black/White/as Request
Flame Test
Yes
Core
Single Core and Multicores
Model No.
Zr-BV, Nh-BV, Bvr, Blx, Byj
Range of Application
Flame Retardant
Specifications
Building Wire
Sample
Yes
Range of Applications
Hook up Wire
Delivery Time
3-10days
OEM&ODM
Yes
Other Model
H07V-K
Size Range
1.5-95 mm2
Color
Red/Green/Blue/Black/White/as Request
Intended for Use
Semi-Flush Exposed Conduits and Embedded Conduits
Conductor Type
Solid/ Stranded/ Flexible
Transport Package
Rolls or According to Cusotmers′ Reques
Specification
0.12 to 400mm2
Trademark
Fengda
Origin
Tianjin, China
HS Code
8544421900
Product Description
Products model:
BVR/BV wire cable
1. Mmultiores pure copper conductor
2. PVC insulated, with or without steel armor, pvc shielded
3. High quality, ISO 9001, CCC, CE, RoHS certified
4. OEM is available.
All models:
BV,BLV,BVR,BVV,BLVV,BVVB,BLVVB,RV,RVB,RVS,RVV
| IEC Code Designation | GB Code Designation | Rated Voltage | Name ( cable/electrical wire) | Application | Rated Temperature |
| 60227 IEC 01 | BV | 300/500V | Copper conductor PVC insulated rigid cable | Fixed laid indoors Instrument etc. | 0°C to +70°C |
| 60227 IEC 05 | BV | 450/750V | |||
| BLV | 450/750V | Aluminum conductor PVC insulated rigid cable | |||
| BVR | 450/750V | Copper conductor PVC insulated semi-flexible cable | Be for laying permanent place where flexible required. | 0°C to +70°C | |
| 60227 IEC10 | BVV | 300/500V | Copper conductor PVC insulated PVC sheathed round rigid cable | Fixed laid, fit for the places with high mechanical protection and moisture place, can be laid in the air or underground. | 0°C to +70°C |
| BLVV | 300/500V | Aluminum conductor PVC insulated PVC sheathed round cable | |||
| BVVB | 300/500V | Copper conductor PVC insulated PVC sheathed flat cable | |||
| BLVVB | 300/500V | Aluminum conductor PVC insulated PVC sheathed flat cable | |||
| 60227 IEC 02 | RV | 450/750V | Copper conductor PVC insulated flexible connector cable | Mainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required | 0°C to +70°C |
| 60227 IEC 06 | RV | 300/500V | |||
| 60227 IEC 42 | RVB | 300/300V | Copper conductor PVC insulated flat flexible connector cable | ||
| RVS | 300/300V | Copper conductor PVC insulated flexible twisting connector cable | |||
| 60227 IEC 52 | RVV | 300/300V | Copper conductor PVC insulated PVC sheathed round flexible connector cable | ||
| 60227 IEC 53 | RVV | 300/500V |
| Description | Installation Place |
| XLPE Insulated, PVC Sheathed Power Cable | Laid in indoor, outdoor, tunnels, cable canals, reinforced concrete pipelines and loose soil. Cable should not bear outer mechanic force, but can bear a certain tractional force. |
| XLPE Insulated, Steel Tape Armored and PVC Sheathed Power Cable. | Laid underground. Cable can bear outer mechanic force, but should not bear large tractional force. |
| XLPE Insulated ,fine Steel Wire Armored and PVC Sheathed Power Cable | Laid in indoor, tunnels and mines. Cable can bear outer mechanic force and fairly large tractional force. |
| XLPE Insulated, thick Steel Wire Armored and PVC Sheathed Power Cable. | Laid in vertical section, indoor, tunnels and mines. Cable can bear outer mechanic force and very large tractional force. |
