Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire

Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire" is a top-quality product from our factory. We specialize in manufacturing high-performance automotive wiring solutions.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
AEX-AVX Wire
Material Shape
Round Wire
Range of Application
Electric Cable for Power
Certification
ISO9001, CE, RoHS
Brand
Hanker
Transport Package
100m/Roll
Specification
0.5-15 mm2
Trademark
HANKER
Origin
China
HS Code
8544492900
Production Capacity
60000m/Month

Product Description


Japanese standard auto wire AV AEX electric motor wire car grounding cable electric wire

Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire

Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire

APPLICATION AND DESCRIPTION

This XLPE insulated single-core cable is used for automobiles, motorcycles and other motor vehicles.

CONSTRUCTION

  • Conductor: Cu-ETP1 according to JIS C3102
  •
  • Insulation: XLPE (AEX)
    Crosslinked PVC (AVX)
  •
  • Standard Compliance: JASO D 608-92

TECHNICAL PARAMETERS

Operating temperature:-40 °C to +120 °C (AEX)
Operating temperature:-40 °C to +100 °C (AVX)

DIMENSIONS AND WEIGHT

  Conductor Construction Insulation Cable
Nominal cross- section No. and Dia. of Wires Diameter
max.
Electrical
Resistance at
20°C
Max.
Thickness
Wall
nom.
Overall
Diameter
min.
Overall
Diameter
max.
Weight
Approx.
mm2 No./mm mm mΩ/m mm mm mm kg/km
1 x0.50 7/0.32 1 32.7 0.5 2 2.2 8
1 x0.85 11/0.32 1.2 20.8 0.5 2.2 2.4 11
1 x1.25 16/0.32 1.5 14.3 0.6 2.7 2.9 16
1 x2.00 26/0.32 1.9 8.8 0.6 3.1 3.4 25
1 x3.00 41/0.32 2.4 5.6 0.7 3.8 4.1 38
1 x5.00 65/0.32 3 3.5 0.8 4.6 4.9 59
1 x8.00 50/0.45 3.7 2.3 0.8 5.3 5.6 86
1 x15.00 84/0.45 4.8 1.4 1.1 7 7.4 145
1 x0.50f 20/0.18 1 36.7 0.5 2 2.2 8
1 x0.75f 30/0.18 1.2 24.4 0.5 2.2 2.4 10
1 x 1.25f 50/0.18 1.5 14.7 0.6 2.7 2.9 16

The "f" in the nominal size column indicates a flexible conductor with a finer wire diameter.
*Note: Other configurations, sizes, colors and length not specified herein are available upon request.
Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire
Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire
Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire



Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire
              Founded in Feb 2010, Hai Yan Hanker Electronic Co.Ltd; is a high-tech enterprise with all vitality, potential and comprehensive strength.
              The company is located in Wu Yuan Industrial Park of Hai Yan District in Jia Xing City and the location is very convenient with good
               transportation links to the neighboring Shang Hai and Ning Bo. On the basis of technology development, the company has taken in a
              group of experienced personnels who are talented in senior management, marketing  and skills of producing. In the company, great
              attention is paid to basic management, stable quality, continuously improving pre-sale service, sale and after-sale services, and enhancing
              the market competitiveness of our products. Main products of our company: Alarm security cable, Telephone cable, Battery cable, Audio
              speaker cable, Amplifier installation kit, Microphone cable, Power cable, Electronic cable, Accessory, etc. Since its foundation, the company
              keeps living up to the belief of :"honest selling, best quality, people-orientation and benefits to customers." We are doing everything to offer
              our customers with best services and best products. We promise that we'll be responsible all the way to the end once our services begin.

Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire Japanese Standard Auto Wire AV Aex Electric Motor Wire Car Grounding Cable Electric Wire
1. Q; Are you manufacture or trading company?
A: We are manufacture has more than 10 years manufacturing experiences.

2.Q: Do you acceptt OEM order?
A: Yes

3.Q: Where is your factory located ?
A: we located in  Haiyan, Jiaxing, Zhejiang, next to shanghai.

4 : Q: Can you offer sampple?
A: Yes, we can offer sample, whether free depend on your detail requirement.

5: Q: What is your payment term?
A: We have several payment terms for you,T/T,Western Union,Paypal,L/C,etc.

6: Q:What about the lead time for mass production?
A:20ft contaniner production tme usually is about 10-15days.
