Basic Info.
Model NO.
60227 IEC 53 RVV
Conductor Material
Copper
Sheath Material
PVC
Insulation Material
PVC
Material Shape
Round Wire
Range of Application
Many Places
Certification
ISO9001
Brand
Bort
OEM
Yes
Color
Customized
Delivery Time
3-10days
Sample
Avaliable
Annual Capacity
300,000kms
Package
Roll,Drum,Spool,Coiled or as Requested
Standard
UL,VDE or Others
Management
ISO9001:2008
Sample Time
3-5days
Packaging Length
610m/Roll or as Requirement
Transport Package
Carton
Specification
Customized
Trademark
Bort
Origin
Fujian China
HS Code
8544492900
Production Capacity
999999meters/Month
Packaging & Delivery
Package Size
20.00cm * 20.00cm * 15.00cm
Package Gross Weight
0.200kg
Product Description
Product Description:
★ Rated temperature:70ºC
Rated voltage:300/500V
★ Reference Standard: GB5023.5-97
★ Bare or tinned, stranded copper conductor
★ Colour-coded lead free PVC insulation
★ Lead free PVC jcaket
★ Application: For general purpose power supply cord
| Product Type | Cores | Conductor | Insulation | Jacket | Maximum Resistance at 20ºC Ω/km | |||||
| Cross Section mm² | No./mm | Dia. mm | Nom. Thick. mm | Nom.Dia. mm | Nom. Thick. mm | Nom.Dia. mm | Bare | Tinned | ||
| 227 IEC 53(RVV)-300/500V | 2 | 0.75 | 24/0.2 | 1.13 | 0.65 | 2.43 | 0.87 | 6.60 | 26.0 | 26.7 |
| 0.75 | 24/0.2 | 1.13 | 0.65 | 2.43 | 0.86 | 4.15×6.58 | 26.0 | 26.7 | ||
| 1.00 | 32/0.2 | 1.30 | 0.65 | 2.60 | 0.87 | 6.94 | 19.5 | 20.0 | ||
| 1.50 | 30/0.25 | 1.57 | 0.76 | 3.10 | 0.87 | 7.94 | 13.3 | 13.7 | ||
| 2.50 | 49/0.25 | 2.05 | 0.85 | 3.74 | 1.11 | 9.70 | 7.98 | 8.21 | ||
| 3 | 0.75 | 24/0.2 | 1.13 | 0.65 | 2.43 | 0.87 | 6.95 | 26.0 | 26.7 | |
| 1.00 | 32/0.2 | 1.3 | 0.65 | 2.60 | 0.87 | 7.34 | 19.5 | 20.0 | ||
| 1.50 | 30/0.25 | 1.57 | 0.76 | 3.10 | 1.01 | 8.70 | 13.3 | 13.7 | ||
| 2.50 | 49/0.25 | 2.05 | 0.85 | 3.74 | 1.22 | 10.5 | 7.98 | 8.21 | ||
| 4 | 0.75 | 24/0.2 | 1.13 | 0.60 | 2.40 | 0.80 | 7.50 | 26.0 | 26.7 | |
| 1.00 | 32/0.22 | 1.3 | 0.60 | 2.54 | 0.90 | 8.00 | 19.5 | 20.0 | ||
| 1.50 | 30/0.25 | 1.58 | 0.70 | 3.10 | 1.00 | 9.60 | 13.3 | 13.7 | ||
| 2.50 | 49/0.25 | 2.02 | 0.80 | 3.70 | 1.10 | 11.36 | 7.98 | 8.21 | ||
*XXmm²: Conductor Cross Section
