Basic Info.
Model NO.
Si
Conductor Material
Copper
Sheath Material
PVC
Material Shape
Round Wire
Range of Application
Flame Retardant
Certification
ISO9001, CE, CCC, RoHS, VDE
Brand
Minzan
Feature
High Temperature Resistance
Feature 2
High Flexibility
Feature 3
Oil Resistant
Feature 4
Waterproof
Feature 5
Moisture-Proof
Feature 6
Anti-Acid and Alkali
Transport Package
100m or 200m Per Roll
Specification
100 or 200 meters
Trademark
Minzan
Origin
China
HS Code
8544110000
Production Capacity
55000 Meters Each Day
Packaging & Delivery
Package Size
30.00cm * 30.00cm * 10.00cm
Package Gross Weight
5.000kg
Product Description
Product Specifications:
Brand Name: MINZAN
Model Number: Si
Product name: Silicon Wire
Certificate: UL ROHS CCC ISO9001 CE
Standard: Q/IRMV2-2008
Insulation: AGV Silicone
Core: Single Core
Rated voltage: 600V
Conductor: Oxygen-Free Copper
Type: Low Voltage
Application: Electrical equipment, equipment wiring, Ectronic internal wiring
MOQ: 100Meter
Jacket: NONE
Armour: NONE
| Specifications (AWG) | Copper wire shares (compos.NO./mm) | Cross Sectional Area(mm²) | Cable diameter (mm) | Jacket thickness | Overall diameter (mm) | max.cond. resistance (Ω/KM,20°C) | Carrying current (ampere) | Standard put-up (m/roll) |
| 95.5mm2 | 19000/0.08TS | 95.5 | 12.73 | 2.64 | 18 | 0.18 | 955 | 50 |
| 1AWG | 15000/0.08TS | 75 | 11.3 | 2.3 | 15.5 | 0.45 | 840 | 50 |
| 2AWG | 10000/0.08TS | 50 | 9.24 | 2.4 | 14 | 0.63 | 630 | 50 |
| 3AWG | 6700/0.08TS | 35 | 7.73 | 2.6 | 13 | 0.89 | 500 | 50 |
| 4AWG | 5000/0.08TS | 25 | 6.53 | 2.4 | 11.5 | 0.9 | 400 | 50 |
| 5AWG | 3998/0.08TS | 20.1 | 5.84 | 1.83 | 9.5 | 1.113 | 350 | 100 |
| 6AWG | 3200/0.08TS | 16 | 5.23 | 1.65 | 8.5 | 1.403 | 300 | 100 |
| 7AWG | 2400/0.08TS | 12 | 4.53 | 1.35 | 7.2 | 1.769 | 240 | 100 |
| 8AWG | 1650/0.08TS | 8.3 | 3.75 | 1.5 | 6.3 | 2.23 | 190 | 100 |
| 9AWG | 1300/0.08TS | 6.53 | 3.33 | 1.24 | 5.8 | 2.813 | 160 | 100 |
| 10AWG | 1050/0.08TS | 5.3 | 3 | 1.3 | 5.45 | 3.546 | 140 | 100 |
| 11AWG | 750/0.08TS | 4 | 2.53 | 1.2 | 5 | 4.48 | 105 | 100 |
| 12AWG | 680/0.08TS | 3.5 | 2.41 | 1 | 4.5 | 5.64 | 88 | 100 |
| 13AWG | 500/0.08TS | 2.5 | 2.07 | 1 | 4 | 7.1 | 70 | 100 |
| 14AWG | 400/0.08TS | 2 | 1.85 | 0.9 | 3.5 | 8.96 | 55 | 200 |
| 15AWG | 300/0.08TS | 1.5 | 1.6 | 0.8 | 3.2 | 11.3 | 42 | 200 |
| 16AWG | 252/0.08TS | 1.27 | 1.47 | 0.75 | 3 | 14.6 | 35 | 200 |
| 17AWG | 210/0.08TS | 1 | 1.33 | 0.68 | 2.7 | 18.3 | 30 | 200 |
| 18AWG | 150/0.08TS | 0.75 | 1.13 | 0.55 | 2.3 | 23.2 | 22 | 200 |
| 20AWG | 100/0.08TS | 0.5 | 0.92 | 0.45 | 1.8 | 36.7 | 13 | 400 |
| 22AWG | 60/0.08TS | 0.34 | 0.72 | 0.45 | 1.7 | 59.4 | 8 | 400 |
| 24AWG | 40/0.08TS | 0.25 | 0.58 | 0.5 | 1.6 | 94.2 | 5 | 400 |
| 26AWG | 30/0.08TS | 0.16 | 0.51 | 0.5 | 1.5 | 150 | 3.5 | 400 |
| 28AWG | 16/0.08TS | 0.08 | 0.37 | 0.4 | 1.2 | 239 | 1.25 | 1500 |
| 30AWG | 11/0.08TS | 0.055 | 0.31 | 0.3 | 0.8 | 381 | 0.8 | 2500 |
FAQ:
1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.Welcome to visit us. We'll pick you up in DONGGUAN.
2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.You'd better order a suitable quantity to avoid the high freight.Sea transportation is the best option.
4. why should you buy from us not from other suppliers?
Specializing in the production of sheathed power cords, towline cables, high-flexible cables, shielded cable series, network cables, multi-core control cables, flat wires, electronic wires, video cables, elevator video cables, etc.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company.
About this product
Minzan's tinned copper silicon wire with silicone insulation is a high-quality option for a variety of electronic and electrical applications. The tinning process helps prevent corrosion and oxidation, and the silicone insulation provides excellent resistance to heat, abrasion, and moisture. This versatile wire is suitable for use in power cords, automotive wiring, and other applications that require reliable and durable wiring. When you choose Minzan's tinned copper silicon wire, you can trust that you are getting a high-performing product that meets industry standards.
